- Frame: Pure Cycles X6 Custom butted, super-light alloy with progressive adventure-ready geometry for stability and comfort, tapered head tube, internal cable routing, dropper post ready, removable fender mounts, rack mounts, multiple water bottle mounts, direct top tube accessory mount, a 12 x 142mm thru-axle, and a flat-mount disc brake mount suitable for 160 mm rotors
- Fork: Pure Cycles carbon monocoque fork with tapered carbon steerer includes internal cable and dynamo routing. It comes with rack, fender, and accessory mounts, a 12 x 100 mm thru-axle, and a flat mount disc brake mount compatible with 160 or 180 mm rotors. Its 48/52 mm adjustable offset Flip-Chip
- Drivetrain: SRAM Apex 1 paired with an FSA 1X crankset and wide range 11-speed cassette for flawless, reliable shifting performance
- Handlebars: Pure Cycles Adventure handlebar featuring a 12-degree flare and shallow drop for comfort and control
- Wheelset: Adventure-ready, tubeless compatible with a 25mm inner rim width, fitted with wide 700 x 40c WTB Venture tires to provide predictable traction on any surface
- Tire Clearance: Supports up to 700 x 50c tires, allowing for a wide range of tire choices for different terrains
- Brakes: TRP Spyre mechanical disc brakes featuring 180mm front rotor and 160mm rear rotor for secure stopping power in all weather conditions
- Chainstay and Chainring Clearance: Accommodates up to a 44T chainring (1x) and 48T (2x) with a 45 mm chain line, ensuring ample space and compatibility
- Also available as a frameset
| Frameset | |
| Frame | X6 Custom Butted Superlight Alloy, 12 x 142 mm thru-axle, flat-mount disc |
| Fork | Carbon Monocoque, Tapered carbon steerer, 12 x 100 mm thru-axle, flat-mount disc, Flip Chip Dropout |
| Drivetrain | |
| Crankset | FSA Omega Direct Mount 1X, 19 mm chromoly spindle |
| Chainring | FSA Omega 1X MegaTooth A, steel, 40T |
| Bottom Bracket | FSA Mega Exo BB-4000, BSA BB |
| Cassette | SRAM PG-1130, 11-42, 11-speed |
| Chain | KMC X-11, Black |
| Rear Derailleur | SRAM APEX 1, Long Cage, 11-speed, 42T max cog |
| Rear Shifter | SRAM APEX, 11-speed |
| Pedals | VP-536, 9/16" |
| Brakes | |
| Front Brake | TRP Spyre C Mechanical Disc, Flat Mount, 180mm Rotor |
| Rear Brake | TRP Spyre C Mechanical Disc, Flat Mount, 160mm Rotor |
| Front Brake Lever | SRAM APEX 1, Mechanical |
| Rear Brake Lever | SRAM APEX, Mechanical |
| Components | |
| Handlebar | Pure Cycles Adventure, 6061 Alloy, 31.8mm Clamp, 12 Deg Flare, 125mm Drop, 80mm Reach |
| Stem | Pure Cycles, 6061 Alloy, +/- 6 deg |
| Headset | 1 1/8" upper - 1 1/2" lower, integrated |
| Grips | EVA Foam, Black with End Caps |
| Saddle | WTB Volt Medium, 142 x 265mm, Steel Rail, Black |
| Seat Post | Alloy w/ two bolt integrated clamp, 27.2 x 350mm, Black |
| Seat Clamp | Alloy, 31.8mm I.D., With Bolt |
| Wheels | |
| Front Wheel | 700c x 32H, 25mm ID, 12mm thru-axle, 6-bolt disc |
| Rear Wheel | 700c x 32H, 25mm ID, 12mm thru-axle, 6-bolt disc |
| Front Hub | Alloy Disc, 32H, 6 bolt, 12 x 100mm thru-axle |
| Rear Hub | Alloy Disc, 32H, 6 bolt, 12 x 142mm thru-axle |
| Spokes | 14G Stainless Steel with alloy nipples (F-290 / D-286 - ND-288 / N-14mm) |
| Rims | 700c x 32H x 14G, PV, Alloy, Black (Designed for tubed & tubeless setup) |
| Tires | WTB Venture / 700 x 40mm, TCS Light, Black Wall |
| Tubes | 700c x 40mm, Super Light Presta Valve (48mm) |
| Weight | |
| Bike Weight | 24.3 lbs. (51 cm) |
| Rider Weight Limit | 275 lb (combined weight of bicycle, rider, and cargo) |
| Notes | |
| Pricing & Specifications | We reserve the right to modify this product’s specifications, colors, and materials without prior notice. Additionally, retail prices may vary from the Manufacturer's Suggested Retail Price (MSRP), which does not include shipping, assembly, or taxes. |
| Frame Size | 45 cm | 48 cm | 51 cm | 53 cm | 56 cm | 59 cm | |
| Seat Tube, Center To Top | A | 45 | 48 | 51 | 53 | 56 | 59 |
| Top Tube, Effective | B | 52.3 | 53.6 | 55.3 | 56.5 | 59.6 | 62.5 |
| Head Tube | C | 12.5 | 14.0 | 15.5 | 17.5 | 19.5 | 21.5 |
| Seat Tube Angle | D | 74.5° | 74° | 73.5° | 73.5° | 73.5° | 73.5° |
| Head Tube Angle | E | 70.5° | 71° | 71.5° | 71.5° | 71.5° | 71.5° |
| Chainstay | F | 43.5 | 43.5 | 43.5 | 43.5 | 43.5 | 43.5 |
| Wheelbase | G | 102.5 | 102.9 | 103.6 | 104.9 | 108.0 | 111.0 |
| Bottom Bracket Drop | H | 7.0 | 7.0 | 7.0 | 7.0 | 7.0 | 7.0 |
| Fork Offset | I | 48 / 52 mm | 48 / 52 mm | 48 / 52 mm | 48 / 52 mm | 48 / 52 mm | 48 / 52 mm |
| Trail | J | 71 / 75 mm | 67 / 71 mm | 64 / 68 mm | 64 / 68 mm | 64 / 68 mm | 64 / 68 mm |
| Axle To Crown | K | 40.3 | 40.3 | 40.3 | 40.3 | 40.3 | 40.3 |
| Stack | L | 55.0 | 56.6 | 58.4 | 60.1 | 62.2 | 63.9 |
| Reach | M | 37.0 | 37.3 | 38.0 | 38.7 | 41.2 | 43.5 |
| Step-Thru / Standover | N | 72.9 | 75.4 | 77.9 | 79.8 | 82.2 | 84.6 |
| Suggested Rider Height | 4'9" - 5'2" | 5'2" - 5'5" | 5'5" - 5'8" | 5'8" - 5'11" | 5'11" - 6'1" | 6'1" - 6'5" | |
| Wheel Size | 700 c | 700c | 700c | 700c | 700c | 700c | |
| Crank Length | 170 mm | 170 mm | 172.5 mm | 172.5 mm | 175 mm | 175 mm | |
| Stem Length | 70 mm | 70 mm | 80 mm | 80 mm | 90 mm | 90 mm | |
| Handlebar Width | 44 cm | 44 cm | 46 cm | 46 cm | 48 cm | 48 cm |
